罗氏线圈DCflex 英国PEM
● thin, flexible, clip-around coil easy to insert in confined spaces
● accuracy typically ±1%
● intrinsically safe, galvanically isolated measurement
● battery powered with an integral display on the enclosure thus no need for external scopes or meters
The DCflex current probe from Power Electronic Measurements Ltdis an easy to use, economical, clip-around DC current probe.
lt is suitable for measuring large dc currents of 2kA and greater.
The probe takes a single shot measurement of the DC current with a typical accuracy of ±1%.
Applications
The DCflex current probe can be used wherever large DC current needs to be measured
● smelting plants
● cathodic protection
● hydro-generation
● DC connection buses between large users
● DC link (large inverter motor drives)
● plating plants
● verifying the performance of large dc shunts or hall effect transducers that are in-situ
Benefits and features
● thin, flexible, clip-around coil easy to insert in confined spaces
● accuracy typically ±1%
● intrinsically safe, galvanically isolated measurement
● battery powered with an integral display on the enclosure thus no need for external scopes or meters
Operation
The DCflex current probe is simple to use
